RC F104 Version II Chassis Kit - F104V.2
ITEM# 58534
In Stock

Share
Tweet
Email
Zoom In
Zoom Out
Zoom Reset
RC F104 Version II Chassis Kit (Item #58534)
  • DESCRIPTION
  • SPECIFICATIONS
  • GALLERY
  • REQUIRED ITEMS

The new F104 version II chassis incorporates a Pivot Ball Link Rear Suspension (PBLR) like the one found on the RM-01 chassis. Compared to the previous 3-point T-bar rear suspension system, this new setup enables more precise adjustments of the chassis' pitch and roll characteristics. Furthermore, the PBLR suspension system features a center pivot ball, an aluminum pitch damper to temper chassis pitch movement, and an aluminum roll damper and side links to control chassis roll. The new layout also increases overall traction and provides greater high speed cornering ability. The proven F104 front suspension remain intact, which features king pin coil springs for the suspension set up.

For a detailed overview of this chassis please view this article.





  <--- Velocity RC Magazine Review


Specification

  • Scale : 1/10 scale
  • Construction type : assembly kit
  • Terrain use : on-road
  • Drive-train : 2WD
  • Drive type : pinion to spur gear
  • Drive line : solid axle
  • Differential type : ball pressure plate
  • Suspension : independent front/solid axle rear
  • Steering mechanism : direct servo
  • Shock damper : oil-filled damper
  • Shock damper material : aluminum
  • Tire type : not included
  • Body material : not included
  • Chassis material : carbon fiber plate
  • Electronic Speed Control (ESC) : not included
  • LED Light buckets : no
  • LED lights : no
  • Motor : not included
  • Bearings : shielded ball bearing
  • Adjustable camber : front only
  • Adjustable toe angles : front only
  • Adjustable ground clearance : yes
  • Adjustable gear ratio : yes
  • Adjustable wheelbase : fixed
  • Adjustable track width : fixed
  • Adjustable shock angle : fixed
  • Special feature 1 : 1/10 assemble R/C Formula 1 kit
  • Special feature 2 : Features 3.0 mm carbon chassis
  • Special feature 3 : Aluminum Parts include: front camber mount; forward shock mount; ball-diff housing; clamp LH wheel hub; steering turnbuckles; F104 servo horn; pivot mount posts; wheel nuts
  • Special feature 4 : Wheels included mount Tamiya foam tires OR racing rubber tires - only items 1031 & 1032 (standard F104 rubber tires require different wheels)
  • Special feature 5 : Alum Roll and Pitch Damper Sets (54341 & 54342) are Included
  • Special feature 6 : Many additional Hop-Up options are available separately
  • Requires A : 7.2 battery & charger
  • Requires B : polycarbonate paint
  • Requires C : 2-channel radio gear
  • Requires D : wheels, tires, body set, motor, esc

Electric Kits Require

  • 2ch Radio sys.

  • Charger

  • Battery Pack

  • PS Spray

  • 8 x AA batteries

  • Tools

(Unless stated differently in products Description or Specifications)
