Rc Tb Evolution V Chassis
-
Description
Introducing the next generation of the shaft driven, high performance TB Evolution R/C racing car. In-depth analysis of the TB Evo IV's racing performance and other driver feedback has enabled TRF designers to fully redesign chassis components to optimize center of gravity and weight balance.
- Steering unit has been located in even lower position, and totally redesigned to incorporate Ackerman steering geometry, realizing sharp and precise linear steering feel.
- Lower bulkhead has been redesigned for more compact, lighter design. New upper and lower bulkheads offer combined weight savings of 11.5g.
- Durable and high precision aluminum diff joint guarantees smooth diff effect under even the toughest conditions. Plastic swing shaft protector reduces friction with diff housing.
- Suspension system utilizes reversible type short span arms to greatly improve responsiveness.
- Normal reversible suspension can be used, greatly increasing setting choices.
-
Specifications
- Adjustable Gear Ratio yes
- Bearings shielded ball bearing
- Body Material n/a
- Chassis Material carbon fiber plate
- Construction Type assembly kit
- Differential Type ball pressure plate
- Discontinued True
- Drive Type shaft
- Led Light Buckets no
- Led Lights no
- Motor not included
- Required To Complete 7.2 battery & charger
- Scale 1/10
- Shock Damper oil-filled damper
- Special Feature 1 Chassis length: 364mm
- Special Feature 2 Width: 188mm
- Special Feature 3 Wheelbase: 257mm
- Special Feature 4 Tread: Front & Rear 160mm
- Special Feature 5 Lower 2.5mm, upper 2.0mm carbon couble deck frame
- Special Feature 6 F/R carbon damper stays have been redesigned
- Special Feature 7 Includes one-piece front one-way and rear ball differential
- Special Feature 8 Small-size bumper for narrower chassis front
- Special Feature 9 Full ball bearings and TRF Super low friction dampers
- Suspension fully independent double wishbone
- Terrain Use on-road
